加工優勢

1. 采用龍門式結構，雙工位工作

2. 導軌采用全封閉防護，環保安全

3. 無接觸式焊接，無機械應力損傷，熱影響小

4. 同軸CCD實時監視系統可清晰觀察焊點效果

5. 帶溫度反饋系統，可以控制焊點溫度

6. 帶CCD自動識別定位系統，可以自動校正位置偏差，保證焊接精度

7. 可以焊接各式PCB的DIP類型加工，咪頭及VCM馬達等產品

ADVANTAGES

1. Using gantry structure, double-station work.

2. All-enclosed protection for guide rail, environmental protection and safety.

3. Contactless welding, no mechanical stress damage, small heat effect.

4. Coaxial CCD real-time monitoring system can clearly observe the effect of solder joints.

5. With temperature feedback system, solder joint temperature can be controlled.

6. Automatic identification and positioning system with CCD can automatically correct position deviation and ensure welding accuracy.

7. It can be used to weld DIP type processing of various PCBs, microphones and VCM motors, etc

技術參數：                                            Technical parameters:
激光功率：100W（可選）                     Laser power: 100W (optional)
運動控制：PLC                                      Motion control: PLC
重復精度：±0.02mm                            Repeat accuracy: ±0.02mm
焊接范圍：300*300mm                       Welding range: 300*300mm
送絲規格：0.3-1.2mm                          Wire feeding specification: 0.3-1.2mm
焊接效率：約1s/point                           Welding efficiency: about 1s/point
電源要求：AC220V 50H                        Power requirements: AC220V 50Hz

應用行業及客戶樣品效果展示：
光通訊，手機數碼，3C電子，智能制造，汽車電子，電聲行業，儀表儀器，航空航天等 。

Application industry and customer sample effect display:
Optical communication, mobile phone digital, 3C electronics, intelligent manufacturing, automotive electronics, electroacoustic industry, instrumentation, aerospace, etc

加工效果EFFECTS
